Chroma 63108A for Rent, Programmable DC Electronic Load Module, 20A, 500V or 600W

Chroma 63108A Highlights

The Chroma 63108A DC Electronic Load Module 500 Volts, 20 Amps, 800 Watts is ideal for the test and evaluation of multi-output AC/DC power supplies, DC/DC converters, chargers and power electronic components. It is designed for applications in research and development, production, and incoming inspection. The system is configured by plugging the user selectable load modules into the system mainframe. The user interfaces include an ergonomically designed user friendly keypad on the front panel and the following computer interfaces: RS-232C, USB or GPIB.

• Up to eight channels in one mainframe, for testing multiple output SMPS
• Parallel load modules up to 1200W for high current and power applications
• Synchronization with multiple loads
• Flexible CC, CR, CP and CV operation modes
• Dynamic loading with speeds up to 20kHz
• Fast response of 0.32mA/_s ~ 10A/_s slew rate
• Minimum input resistance allows the load to sink high current at low voltages
• Real time power supply load transient response simulation and output measurements
• User programmable 100 sequences. Front panel input status for user-friendly operation
• High/Low limits of testing parameters to test GO/NG
• Digital I/O control
• Over current protection (OCP) testing function
• 16-bit precision voltage and current measurement with dual-range
• Remote sensing capability
• Short circuit test
• Self-test at power-on
• Full Protection: OC, OP, OT protection and OV, reverse alarm
• USB, GPIB & RS-232C interfaces
• Dynamic loading with speeds up to 20kHz; Flexible CC, CR, CP and CV operation modes
