Chroma 63206A-150-600 for Rent, High Power DC Electronic Load, 150V, 600A, 6kW
High Power DC Electronic Load, 150V, 600A, 6kW

Order #: 63206A-150-600-RENT3

Mfg #: 63206A-150-600

Questions about availability or need help? Contact Us:

(800) 633-0561
Call for price
Call for price

Chroma 63206A-150-600 for Rent, High Power DC Electronic Load, 150V, 600A, 6kW

High Power DC Electronic Load, 150V, 600A, 6kW

Order #: 63206A-150-600-RENT3

Mfg #: 63206A-150-600

For Rent
Loading...
Print Email Save Item Compare
Call for price

Request a Rental Quote

Have a Question? Speak to a Transcat Rental Expert: 800.264.4059

Call for price
Register to view exclusive member pricing

Product Highlights

Chroma's 63206A-150-600 programmable DC electronic load with a digital signal microprocessor (200MHz) built in has the optimal speed and control performance. The ultra high density power not only saves room, its super high voltage (0.015%+0.015%F.S.) and current (0.04%+0.04%F.S.) measurement accuracy ensures the fidelity of results. These are designed for testing a wide range of power conversion products including AC/DC and server power supplies, DC/DC converters, EV batteries, automotive charging stations, and more. The Chroma 63206A-150-600 DC electronic loads operate in constant voltage, current, resistance, or power modes to satisfy a wide range of test requirements.

Each model of the Chroma 63206A-150-600 DC load has 3 power ranges, they can precisely measure the voltage and current in real time. The Chroma 63206A-150-600 programmable DC load has a unique sine wave loading function which allows setting of a current bias, a loading sine wave and sine wave frequency. It also offers a unique dynamic frequency sweep with variable frequencies up to 50kHz. The dynamic loading mode can simulate different loading conditions for most test requirements. Besides a built-in highly precision A/D converter, it achieves 0.015%+0.015%F.S., 0.04%+0.04%F.S. and 0.1%+0.1%F.S. accuracy for voltage, current and power measurement respectively. Precise measurements like these are ideal for testing power efficiency and other critical parameters of the UUT's.

The Chroma 63206A-150-600 programmable DC electronic loads can be operated from the front panel controls or from available softpanel. This user friendly software includes all functions and is easy to understand and operate. They can be controlled via GPIB, USB and Ethernet interfaces for remote control and automated testing applications.

  • Voltage: 0-150V (Mid)
  • Current: 0-60A, 0-300A, 0-6000A
  • Power: 0-6000W (Mid)
  • Min Operating Voltage: 0.18V@60A, 0.9V@300A, 1.8V@6000A
Technical Resources
Chroma 63206A-150-600 Datasheet
