Chroma 62020H-150S for Rent, Programmable DC Power Supply 150V, 40A, 2KW with Solar Array Simulation

Product Highlights

The Chroma 62020H-150S Programmable DC Power Supply offers many unique advantages for telecom, automated test system & integration, industrial, battery charge & simulation for hybrid cars and solar panel simulation. These advantages include high power density of 15KW in 3U, precision readback of output current and voltage, output trigger signals as well as the ability to create complex DC transient waveforms to test device behavior for spikes, drops, and other voltage deviations.

The Chroma 62020H-150S Programmable DC Power Supply can easily parallel up to ten units capable of 150KW with current sharing for bulk power applications, for example, battery bank simulation of 450V/150A/67.5KW for electric vehicle and military use.

There are 100 user programmable input status on the front panel for automated test application and life cycle ON/OFF test. In addition, the Chroma 62020H-150S Programmable DC Power Supply has a 16 bit digital control with bright vacuum fluorescent display readout.

The Chroma 62020H-150S Programmable DC Power Supply is very easy to operate either from the front panel keypad or from the remote controller via USB / RS232 / RS485 / APG (Standard) and GPIB & Ethernet (optional). Its compact size with 3U only can be stacked on a bench in a standard rack without any difficulty.

Another unique capability of the Chroma 62020H-150S Programmable DC Power Supply is its ability to create complex DC transient waveforms. This capability allows devices to be tested to DC voltage dropouts, spikes and other voltage variations making them an ideal choice for aerospace device testing, inverter testing and other devices which will experience voltage interrupts. Applications include DC/DC converter & inverter voltage drop test, engine start-up simulation, battery automated charging, electronic product life cycle test, etc.

Features and Specifications of the Chroma 62020H-150S Programmable DC Power Supply include:

• Power Range:  2KW
• Voltage Range:  0-150V
• Current Range:  0-40A
• High power density (2KW in 2U)
• Easy master / slave parallel & series operation
• Precision V&I Measurements
• High-Speed programming
• Voltage & Current slew rate control
• Digital encoder knobs, keypad and function keys
• Current sharing operation
• Voltage ramp function (time range: 10 ms - 99 hours)
• Auto sequencing programming: 10 programs / 100 sequences
• OVP, current limit, thermal protection
• Standard analog programming interface
• Standard USB / RS232 / RS485 interface
• Optional GPIB / Ethernet interface
• Remote output ON / OFF (I / P)
• Remote sense line drop compensation
• LabView and Labwindows
• Solar array simulation function
• Shade I-V curve simulation
• I-V curve programming: 10 program / 100 I-V files
• CE certified
