Fluke ii900 Sonic Industrial Imager for leak detection, Ultra Sonic Leak Detection
Sonic Industrial Imager for leak detection, 7in LCD
Order #: II900
Mfg #: 5075603
Special Price
$17,512.49
Regular Price
$23,349.99
Fluke ii900 Sonic Industrial Imager for leak detection, Ultra Sonic Leak Detection
Sonic Industrial Imager for leak detection, 7in LCD
Order #: II900
Mfg #: 5075603
Special Price
$17,512.49
Regular Price
$23,349.99
Equipped with an array of microphones for an expanded field-of-view, the handheld Fluke ii900 Sonic Industrial Imager enables maintenance teams to quickly and accurately locate air, gas and vacuum leaks in compressed air systems; even in noisy environments.
Availability:
In stock
Product Highlights
Product Highlights
The handheld Fluke ii900 Sonic Industrial Imager is designed for production facilities that rely on compressed air. With minimal training, maintenance teams can now inspect for air and vacuum leaks even during peak production periods. Equipped with a microphone array and the ability to easily isolate the sound frequency to identify leaks, background noise can be filtered, and leaks are easily identified. The 7" LCD touchscreen overlays a SoundMap
- NEW: Leak volume and cost indication on the go
- NEW: CO2 emission reporting
- Improve energy efficiency. Do more with the same air compressors and delay the capital expense of purchasing an additional compressor
- Lower utility and downtime costs
- Reduce time and costs to detect leaks
- Improve production process and pneumatic equipment reliability
-
Fluke BP291 HZM Li-ion Battery Pack for ScopeMeter 190 Series IIHZM Li-ion Battery Pack for ScopeMeter 190 Series IIOrder #: BP291
Mfg #: 3894688
Availability:In stockSpecial Price $385.11 Regular Price $463.99 -
Fluke II900 ARRAY CVRS Replacement Array Cover for ii900 Sonic Imager, Set of 2Replacement Array Cover for ii900, Set of 2
Order #: FLK-II900 ARRAY CVRS
Mfg #: 5075982
Availability: Ships in 3-4 weeks$98.99View details -
Fluke II900 HAND STRAP Replacement Hand Strap for ii900 Sonic ImagerReplacement Hand Strap for ii900 Sonic Imager
Order #: FLK-II900 HAND STRAP
Mfg #: 5075994
Availability: Ships in 3-4 weeks$41.99 -
Fluke EDBC290 External Dual Bay Charger with Power Adapter & ConnectorsExternal Dual Bay Charger w/Power Adapter & Connectors
Order #: EDBC290
Mfg #: 5077735
Availability: Ships in 3-4 weeks$519.99 -
Fluke RSE-RJ45-25 Ethernet Cable Office Grade, 82' (25m)Ethernet Cable Office Grade 82ft.(25m)
Order #: FLK-RSE-RJ45-25
Mfg #: 4961590
Availability: Ships in 3-4 weeks$131.99
| Sensors | |
|---|---|
| # of microphones | 64 digital MEMS microphones |
| Frequency band | 2 kHz to 52 kHz |
| Sound pressure sensitivity | Detects a 0.005 CFM leak at 100PSI from up to 32.8 feet (Detects a 2.5 cm3/sec leak at 7 bar from up to 10 meters) |
| Operation distance range | 0.5 to > 50 meters (1.6 to > 164 feet)* |
| Field of View | 63 ° ± 5 ° |
| Minimum Frame Rate | 12.5 FPS |
| *Depending on ambient conditions | |
| Built-in digital camera (visible light) | |
|---|---|
| Field of View (FOV) | 63 ° ± 5 ° |
| Focus | Fixed lens |
| Display | 7" LCD with backlight, under-sunlight readable |
|---|---|
| Resolution | 1280 x 800 (1,024,000 pixels) |
| Touchscreen | Capacitive |
| Acoustic Image | Yes, SoundMap™ image |
| Image storage | |
|---|---|
| Storage capacity | Internal memory with the capacity for 999 picture files or 20 video files |
| Image format | Blended visual and SoundMap™.JPG or .PNG |
| Video format | Blended visual and SoundMap™.MP4 |
| Video length | 30 seconds |
| Digital export | USB-C for data transfer |
| Acoustic Measurements | |
|---|---|
| Measurement range | 29.3 dB to 119.6 dB SPL (±2 dB) at 2 kHz 21.9 dB to 112.3 db SPL (±2 dB) at 19 kHz 36.6 db to 126.9 dB SPL (±2 dB) at 52 kHz |
| Auto max/min dB gain | Auto or manual, user selectable |
| Frequency band selection | User selectable through user-made presets or manual entry |
| Software | |
|---|---|
| Ease of use | Intuitive user interface |
| Trend graphs | Frequency and dB scale |
| Spot markers | dB level reading at center point of the image |
| Battery | |
|---|---|
| Batteries (field-replaceable, rechargeable) | Rechargeable Li-ion, Fluke BP291 |
| Battery life | 6 hours (product includes spare battery) |
| Battery charging time | 3 hours |
| Battery charging system | External dual-bay charger, EDBC 290 |
| General Specifications | |
|---|---|
| Standard palettes | 3: Grayscale, Ironbow, Blue-Red |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature | -20 °C to 70 °C (-4 °F to 158 °F) Without batteries |
| Relative humidity | 10 % to 95 % non-condensing |
| Size (H x W x L) | 186 mm x 322 mm x 68 mm (7.3 inches x 12.7 inches x 2.7 inches) |
| Weight (battery included) | 1.7 kg (3.75 pounds) |
| Main unit rating | IP40 protection against particles 1mm or greater and dripping water |
| Sensor head rating | IP51 |
| Warranty | 2 year |
| Self-diagnostic notification | Array-health test to identify when microphone array needs attention |
| Supported languages | Dutch, English, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
| RoHS compliant | Yes |
| Safety | |
|---|---|
| General Safety | IEC 61010-1 |
| Electromagnetic Compatibility (EMC) International | IEC 61326-1: Portable Electromagnetic Environment IEC 61326-2-2 CISPR 11: Group 1, Class A |
| Korea (KCC) | Class A Equipment (Industrial Broadcasting & Communication) |
| USA (FCC) | 47 CFR 15 subpart B. This product is considered an exempt device per clause 15.103. |
Benefits of the Fluke ii900 Sonic Industrial Imager
Justin from Fluke discussing the benefits of the revolutionary ii900 Sonic Industrial Imager that helps find compressed air and gas leaks.
