Narda 3003-10 for Rent, Directional Coupler, 2 - 4GHz Coaxial
Directional Coupler, 2 - 4GHz Coaxial
Order #: 3003-10-RENT2
Mfg #: 3003-10
Call for price
Call for price
Narda 3003-10 for Rent, Directional Coupler, 2 - 4GHz Coaxial
Directional Coupler, 2 - 4GHz Coaxial
Order #: 3003-10-RENT2
Mfg #: 3003-10
Call for price
Request a Rental Quote
Have a Question? Speak to a Transcat Rental Expert: 800.264.4059
Call for price
Availability: Call for Availability
![Loading...](https://www.transcat.com/static/version1724161005/frontend/Transcat/default/en_US/images/loader-1.gif)
Narda 3003-10 Highlights
- RF Directional Coupler
- Low Frequency (GHz): 2.0
- High Frequency (GHz): 4.0
- Nominal Coupling (dB): 10
- Minimum Directivity (dB): 25
- Insertion Loss, Coupled Power Excluded (dB): 0.20
- True Insertion Loss (dB): 0.70
- VSWR Maximum for Primary Line: 1.15
- VSWR Maximum for Secondary Line: 1.20
- Calibration (Freq GHz): 2.0, 2.5, 3.0,3.5, 4.0
- Absolute Calibration Accuracy dB (per 10 dB step): +/- 0.1
- Maximum Deviation from Nominal (dB): +/- 1.2
- Power Incident (Watts): 200
- Power Reflected (Watts): 50
- Peak Power (kW): 10
