Siglent SPD1305X

DC Power Supply,4-Digit Display Up to 150W

Order #: SPD1305X

Mfg #: SPD1305X

New

$285.00

Availability: Call for availability

Single path high-precision programmable voltage output:

Stable, reliable, Low ripple and noise_≤ 350 uVrms/3 mVpp; < 2 mArms

Fast transient response time: < 50 µs

5 digit Voltage, 4 digit Current Display, Minimum Resolution: 1 mV/1 mA

Supports front panel timing output functions

2.8 inch true color TFT- LCD 240 x320 display

2 types of output modes: Two-wire output mode, 4-wire compensation output mode, Maximum compensation voltage 1V.

100/120/220/230 V compatible design to meet the needs of different power grids

Intelligent temperature-controlled fanreduces noise

Clear graphical interface, with the waveform display function

Internal 5 groups of system parameter save/recall

Siglent SPD1000X Datasheet
