Keysight N9324C Basic Spectrum Analyzer, 1 MHz to 20 GHz
Basic Spectrum Analyzer, 1 MHz to 20 GHz

Order #: N9324C

Mfg #: N9324C

Questions about availability or need help? Contact Us:

(800) 633-0561
$24,761.00

Keysight N9324C Basic Spectrum Analyzer, 1 MHz to 20 GHz

Basic Spectrum Analyzer, 1 MHz to 20 GHz

Order #: N9324C

Mfg #: N9324C

New
Loading...
Print Email Save Item Compare
$24,761.00
Register to view exclusive member pricing
Availability: Ships in 4-6 weeks

 Ships Free Over $100

This product is available for shipping to the United States and Canada only.
This product is available for shipping to the United States and Canada only.
This product is available for shipping to the United States and Canada only.

Product Highlights

Easy on Your Budget. Tough to Beat Performance.

The N9324C Basic Spectrum Analyzer makes higher productivity achievable on a smaller budget with proven test efficiency, best-in-class usability and flexibility to adapt to new requirements.

  • Make fast RF spectrum analysis covering frequency 1 MHz to 20 GHz
  • Equipped with tracking generator for stimulus response tests
  • Powerful spectrum monitoring feature allows identifying interfering signals arising from unwanted or unexpected transmissions
  • Support AM/FM, ASK/FSK demodulation analysis suites for IoT transmitter characterization
  • Implement up to 20 pre-defined measurements automatically and reduce test setup time by 95% with the task planner feature
  • Achieve straightforward and efficient operation with marker demodulation, one-button optimization, and user-definable soft keys

Each Unit Includes

Accessories supplied as standard with each analyzer: USB cable, N-BNC adapter, BNC cable and power cord.

Win a Generac Generator when purchasing $750 or more from Transcat.Win a Generac Generator when purchasing $750 or more from Transcat.
Accessories
  1. Keysight Y1820A Hard transit case, 645 x 444 x 268 mm, 13 kg nominal
    Keysight Y1820A Hard transit case, 645 x 444 x 268 mm, 13 kg nominal
    Hard transit case, 645 x 444 x 268 mm, 13 kg nominal

    Order #: Y1820A

    Mfg #: Y1820A

    Availability: Ships in 4-6 weeks
    $601.00
  2. Keysight Y1821A Rack mount kit
    Keysight Y1821A Rack mount kit
    Rack mount kit

    Order #: Y1821A

    Mfg #: Y1821A

    Availability: Ships in 4-6 weeks
    $157.00
  3. Keysight Y1822A Rack mount kit with handle
    Keysight Y1822A Rack mount kit with handle
    Rack mount kit with handle

    Order #: Y1822A

    Mfg #: Y1822A

    Availability: Ships in 4-6 weeks
    $298.00
  4. Keysight N9324C-P20 Preamplifier, 20 GHz
    Keysight N9324C-P20 Preamplifier, 20 GHz
    Preamplifier, 20 GHz

    Order #: N9324C-P20

    Mfg #: N9324C-P20

    Availability: Ships in 4-6 weeks
    $2,377.00
Specifications
Frequency Range 1 kHz - 20 GHz
Reference Aging Rate ± 1 ppm, ± 0.1 ppm (w/Opt. PFR)
Absolute Amplitude Accuracy ± 0.3 dB
Displayed Average Noise Level, 1 GHz (typical) -154 dBm/Hz
Resolution Bandwidth 10 Hz - 3 MHz
Third-Order Intercept (TOI) +9 dBm
Input Attenuator 0 to 50 dB, in 5 db steps
Phase Noise, 100 kHz offset -97 dBc/Hz
Technical Resources
Keysight N9321C/22C/23C/24C User Manual
Keysight N9321C/22C/23C/24C Configuration Guide
Keysight N9321C/22C/23C/24C Programmer Guide
