Keysight 8494A Manual Step Attenuator, 4GHz 11dB, 1dB Steps
Manual Step Attenuator,4GHz 11dB,1dB Steps
Order #: 8494A
Mfg #: 8494A
$1,635.00
Keysight 8494A Manual Step Attenuator, 4GHz 11dB, 1dB Steps
Manual Step Attenuator,4GHz 11dB,1dB Steps
Order #: 8494A
Mfg #: 8494A
$1,635.00
Availability: Ships in 3-4 weeks
Product Highlights
- Frequency Range: dc to 4 GHz
- Insertion Loss at 0 dB: 0.6 dB + 0.09 dB/GHz
- Maximum SWR: 1.5
- Repeatability life: 0.03 dB max 5 million cycles per section, typical
- 5 million cycles per section
- Maximum RF Input Power: 1 W (average), 100 W (peak)
- Connector Type: choice of Type-N female, SMA female, APC-7
- Connect in series with 11716A Attenuator Interconnect Kit, Type-N
- Connect in series with 11716C Attenuator Interconnect Kit, SMA
