Keysight 8495H Programmable Attenuator, 18GHz 70dB, 10dB Steps

Product Highlights

• Frequency range: dc to 18 GHz
• Insertion loss at 0 dB: 0.4 dB + 0.07 dB/GHz
• Maximum SWR: 1.35 to 8 GHz, 1.5 to 12.4 GHz, 1.7 to 18 GHz
• Repeatability life: 0.03 dB max 5 million cycles per section, typical
• 5 million cycles per section
• Maximum RF input power: 1 W (average), 100 W (peak)
• Connector type: choice of type-N female, SMA female, APC-7
• Programming connector: 12-pin Viking, optional 14-pin DIP
