Test Products International 440

Product Highlights

• Size: 2” x 3” (51mm x 76mm)
• Pixels: 160 x 240
• Backlight
• External 16V DC power supply
• Internal 7.2V DC rechargeable battery
• Operating Time 5 hours
• Charging Time 3 Hours
• Memory: Waveform, save 4 full screens
• VERTICAL: Bandwidth: 1 MHz Resolution: 8 bits, 1 Channel, Coupling: AC, DC Input, Impedance: 1.11M, Ohm Accuracy: ± 3%, Max Input Voltage: 1000Vp-p, Trigger Source: Internal Trigger Slope: Positive / Negative
• HORIZONTAL: Sample Rate: 20 Mega samples/second, Samples per Division: 20, Update Rate: Real time, Modes: Single shot, Accuracy +/-0.05%, Sweep Rate: 1uS to 1S in 1,2,5 sequence
• TRUE RMS DMM: DCV: 400mV, 4, 40, 400, 1000V, Basic DC Accuracy: ± 0.3%, ACV: 300mV, 3, 30, 300, 750V , Basic ACV Accuracy: ± 0.75%, DC Amps: 400uA, 4000uA, 40mA, 400mA 4A, 10A, Basic DCA Accuracy: ± 0.5%, AC Amps: 300uA, 3000uA, 30mA, 300mA 3A, 10A, Basic DCA Accuracy: +/-0.75%, Frequency: 1 Hz to 2 MHz, Basic Frequency Accuracy: ± 0.05%, Capacitance: 400nF, 4uF, 40uF, 400uF, Basic Capacitance Accuracy: +/-3%, Resistance (Ohm): 400 Ω, 4k Ω, 40k Ω, 400k Ω, 4M Ω, 30M Ω, Basic Ohm Accuracy: ± 0.3%, Continuity (CH1 only) < 100 ohm , Diode Test: 2.5mA maximum output

Each Unit Includes

• Insulated Test Leads with Alligator Clips
• Power Supply
• NiCad Battery
• Instruction Manual
