BK Precision 4078C 30 MHz Dual Channel Function/ Arbitrary Waveform Generator
30 MHz Dual Channel Function/ Arbitrary Waveform Generator

Order #: 4078C

Mfg #: 4078C

Questions about availability or need help? Contact Us:

(800) 633-0561
$2,250.00

BK Precision 4078C 30 MHz Dual Channel Function/ Arbitrary Waveform Generator

30 MHz Dual Channel Function/ Arbitrary Waveform Generator

Order #: 4078C

Mfg #: 4078C

$2,250.00
Availability: Ships in 3-4 weeks

Product Highlights

The 4078C Series Arbitrary/Function Waveform Generators are versatile high-performance dual-channel arbitrary waveform generators comprised of a 30 MHz and 50 MHz model. They provide variable output voltages from 0 to 10 Vp-p into 50 ohms or up to 20 Vp-p into an open circuit, and a DC offset to bias the output signal at a desired level.

With up to 250 MSa/s sampling rate and 16-bit amplitude resolution, these instruments produce high fidelity waveforms without skipping points. Easily generate arbitrary waveforms of up to 4 million points from the front panel using the built-in editor tool. Additional features include AM, FM, and FSK modulation, frequency sweep capabilities, and variable edge pulse generation.

Features

  • Generate waveforms up to 30 MHz (4078C) and 50 MHz (4079C)
  • 2 channels with dedicated output ON/OFF buttons for each channel
  • Up to 250 MSa/s sampling rate
  • Waveform length up to 4 Mpts/ch
  • 16-bit amplitude resolution
  • Linear and logarithmic sweep
  • Modulation techniques include: AM, FM, PM, BPSK, and FSK
  • Continuous, triggered, burst, and gate modes
  • Internal/external triggering and programmable markers
  • Variable DC offset ± 5 V
  • Low jitter < 25 ps
  • 4.3-inch LCD and internal memory to store/recall instrument setups
  • USB (USBTMC-compliant) and LAN interfaces standard
  • Overload protection of outputs
  • cTUVus certification marks fulfills CSA and UL safety standards
