Used Additel ADT680W-05-V15-PSI-N Digital Pressure Gauge, -15 to 0 psi, 1/4NPT M

Product Highlights

• Pressure ranges to 60,000 psi (4,200 bar)
• Now offering 0.05% accuracy up to 40K psi
• 0.05%, 0.1% or 0.25%FS accuracy
• Fully temperature compensated accuracy
• IP67
• Data logging and wireless (680W)

We designed the 680 series digital pressure gauges with two main objectives in mind. First, to provide an affordable digital gauge to replace mechanical gauges. If you're looking to move from dial gauges to a digital gauge, you'll find the 680 standard version gauge to be of high quality and suited for your need in terms of price and performance. With advanced microprocessor technology and state-of-the-art silicon pressure sensors, the 680 series digital pressure gauges provide an accurate, reliable, and economic solution for a wide range of pressure applications. They are loaded with functionality and remarkably easy to use. To reach the best performance, every silicon pressure sensor is specially aged, tested and screened before assembly.

The second objective was to provide a high-precision pressure gauge capable of wireless communication and data logging. Our 680W series provides just this along with several accuracy and pressure range options to meet your need. This wireless unit is compatible with the Additel/Land Wireless software, which is available for a free download from our website. Data can be recorded standalone with the 680W and then downloaded wirelessly to Additel/Land Wireless. For more advanced logging and data analysis, Additel/Log II Wireless is specially designed to communicate with the 680W. Each unit can store up to 140,000 readings which consist of date, time, pressure, and internal temperature. The 680 series digital pressure gauges are unmatched in performance and reliability. Best of all they are very affordable.

• Pressure ranges to 60,000 psi (4,200 bar)
• 0.05%, 0.1% or 0.25% full span accuracy
• Fully temperature compensated accuracy from 14°F to 122°F (-10°C to 50°C)
• Up to 13 user-selectable pressure units, 6 selectable engineering units
• Large, easy to read display with 5-digit resolution
• Backlit display
• Icon-based menu
• Display flash warning when pressure exceeds 120% of FS
• Stainless wetted surface construction
• IP67 (submersible in 1 meter of water)
• Drop-tested from 1 meter
• 2 AA alkaline batteries
• CE R&TTE, FCC ID, IC ID Certificates
• ISO 17025 accredited calibration with data(included)
