RIGOL DSA710

Measurement for Remote controller, car keys and other signals based on 2FSK modulation, not only retains the stable and integration of digital spectrum analyzer, but also the ripid capture characteristic of anolog spectrum analyzer.

It is the most cost-effective EMI pre-compatibility testing tool. The built-in testing function of the tool can help engineers to quickly locate the problems of the products being measured, enabling the products to pass the testing conducted by EMC.

Product Highlights

• Frequency range from 100kHz to 1GHz
• Displayed average noise level (DANL) <-155dBm/Hz typ. with preamplifier on
• Minimum resolution bandwidth (RBW) 100Hz
• Phase noise <-80dBc/Hz @10kHz offset
• Level measurement uncertainty <1.5dB
• 8" (800 x 480) high-definition display
• Linear and logarithmic frequency axis
• Connectivity: LAN(LXI), USB Host & Device
• PictBridge support
• Compact size and light weight
• Supplied with... USB cable, UK & European mains leads, quick guide,
• Optional PC software... Ultra Spectrum, S1210 EMI Pre-Compliance Test
• Other options include... EMI filter & quasi-peak detector, advanced measurement functions, 2FSK measurement & analysis in signal seamless capture mode, USB to GPIB module, rack mount kit, soft carry bag, RF transmitter demo kit, RF receiver demo kit, high power attenuator, RCL standard calibration
