Used Shimpo FGE-500HXY High Capacity Digital Force Gauge, 500 lbs.
High Capacity Digital Force Gauge, 500 lbs.
Order #: FGE-500HXY-USED
Mfg #: FGE-500HXY
Call for price
Call for price
Used Shimpo FGE-500HXY High Capacity Digital Force Gauge, 500 lbs.
High Capacity Digital Force Gauge, 500 lbs.
Order #: FGE-500HXY-USED
Mfg #: FGE-500HXY
Call for price
Request a Used Instrument Quote
Have a Question? Speak to a Transcat Expert: 800.264.4059
Transcat Used Instrument Guarantee
Calibration Certificate Included 6 Month Warranty Unsurpassed Service & Support
Call for price
Availability: Call for Availability
![Loading...](https://www.transcat.com/static/version1724161005/frontend/Transcat/default/en_US/images/loader-1.gif)
Product Highlights
- 1000 Hz Sample Rate provides faster sampling producing better resolution and more accurate results
- Ideal for strict tolerances with its high accuracy +/-0.2% F.S.
- Measure and record compression and tension tests. Permits true "push-pull" testing
- Included handle attachments aid in user testing
- 180° Reversible display and dual printed keypad allows usage as a portable gauge or mounted upside down on a test stand
- 1 million operation load cell with superior overload protection provides a long-life, damage free product
- High-capacity rugged, ergonomic die cast aluminum construction allows usage on production floor
- Variable display response rate aids viewing readings
- Quick retrieval of peak measurement with a single push button in test stand
- Flexible user preference with one button selection of engineering units
- Field calibration through keypad eliminates down time
- On board statistics provides immediate results and analysis of test data
- Dual power capable with rechargeable battery or AC line voltage
- Include data collection flexibility with 3 outputs: USB, RS-232 & Analog Output
- Expanded memory for reviewing data points and transferring to PC/Laptop
- Provide Built-In Hi-Lo Comparator function provides user with easy
