Fluke 754 Documenting Process Calibrator with HART Instrument
Documenting Process Calibrator with HART Instrument
Order #: 754
Mfg #: 3405771
Special Price
$8,643.61
Regular Price
$10,413.99
Fluke 754 Documenting Process Calibrator with HART Instrument
Documenting Process Calibrator with HART Instrument
Order #: 754
Mfg #: 3405771
Special Price
$8,643.61
Regular Price
$10,413.99
Availability:
In stock
SAVE OVER $770! FREE Tools include:
- Fluke TL175 TwistGuard Test Leads
- JKTE Mini Plug Set
- Leatherman SIDEKICK Multi-Tool
- Fluke BC7240 Battery Charger
- Fluke BP7240 HZM Li-ion Battery Pack
- Hard carrying Case
- Pack of 128 Self Laminating Green Calibration Labels
Fluke 754 Overview
You're going to love what we've done with your calibrator.
The 754 is everything you needed and wished for in the 744 and more! HART communication capability is combined to deliver an integrated communicating calibrator. This rugged, reliable tool is ideal for calibrating, maintaining, and troubleshooting HART and other instrumentation.
The 754 does the work of several tools - sourcing, simulating and measuring pressure, temperature, and electrical signals in one rugged, hand-held device. You'll fall in love with the new improved graphical screen, Li-Ion battery for longer life, USB port and new accessories to complete the package.
For documentation, the 754 automates calibration procedures and captures your data. And, of course, it helps you meet rigorous standards like ISO 9000, FDA, EPA and OSHA regulations.
HART Capabilities
The 754 is designed to take on nearly all the day-to-day tasks you now perform with a separate communicator. In fact, it offers most of the communication capabilities of a HART communicator.
Fluke 754 Highlights
- Measure volts, mA, RTDs, thermocouples, frequency, and ohms to test sensors, transmitters and other instruments
- Source/simulate volts, mA, thermocouples, RTDs, frequency, ohms, and pressure to calibrate transmitters
- Power transmitters during test using loop supply with simultaneous mA measurement
- Measure/source pressure using any of 29 Fluke pressure modules
- Advanced features like autostep, custom units, user entered values during test, one-point and two-point switch testing, square root DP flow testing, programmable measurement delay and more
- Includes HART communication for adjusting and testing HART smart transmitters.
- Includes the new C799 Field soft case
- Three-year warranty
Each Fluke 754 Includes
- Three sets of stackable test leads
- Three sets of TP220 test probes with three sets of "extended tooth" alligator clips
- Two sets AC280 hook clips
- BP7240 Li-ion battery pack
- BC7240 battery charger
- C799 field soft case
- USB communication cable
- Getting started guide
- Instruction manual on CDROM
- NIST traceable certificate of calibration
- DPCTrack™ 2 sample software
- HART communication cable
Webinars
Automating and Documenting Temperature Calibration Webinar with Fluke Calibration
Differential Pressure Meter Gas Custody Transfer Calibration Webinar with Fluke
-
Fluke 750P Series Pressure ModulesConfigure your Fluke 750 Series Pressure Module today!Order #: 750P
Mfg #: 750P
Availability:In stock$1,713.99 -
Transcat 5353C-GCalibration Labels-Green, Self-Laminating, 1 3/4x5/8"
Order #: 5353C-G
Mfg #: CUSTOM QCC306-GR (QZ0530GR)
Availability:In stockSpecial Price $22.94 Regular Price $24.15 -
Fluke 700LTP-1 Low Pressure Test Pump, 100PSI (7 BAR)Low Pressure Test Pump, 100PSI/7 BAR
Order #: 700LTP-1
Mfg #: 2811763
Availability: Ships in 2-3 weeks$1,072.99 -
Fluke 700PMP Hand Pressure Pump, 150 psi, 1000 kPaHand Pressure Pump, 150 psi, 1000 kPa
Order #: 700PMP
Mfg #: 617131
Availability:In stockSpecial Price $559.41 Regular Price $673.99 -
Fluke 700PTP-1 Pneumatic Test Pump, -13 to 600PSIPneumatic Test Pump, -13 to 600PSI
Order #: 700PTP-1
Mfg #: 2811774
Availability: Ships in 4-6 weeks$1,058.99 -
Fluke 700PCK Pressure Module Calibration KitPressure Module Calibration Kit
Order #: 700PCK
Mfg #: 100062
Availability:In stock$1,875.99 -
Fluke 700HTH Hydraulic Test HoseHydraulic Test Hose
Order #: 700HTH-1
Mfg #: 2811795
Availability:In stockSpecial Price $668.14 Regular Price $804.99 -
Fluke 700PRV-1 Pressure Relief Valve KitPressure Relief Valve Kit Valve Kit
Order #: 700PRV-1
Mfg #: 2811808
Availability: Call for availabilitySpecial Price $782.68 Regular Price $942.99 -
Fluke 750 SW DPC/TRACK2 Calibration Management SoftwareCalibration Management Software
Order #: 750SW
Mfg #: 4090343
Availability:In stock$5,332.99 -
Fluke C799 Soft Field Case Soft Field CaseSoft Field Case
Order #: C799
Mfg #: 4021731
Availability:In stockSpecial Price $177.61 Regular Price $213.99 -
Fluke 700TLK Process Test Lead KitProcess Test Lead Kit
Order #: 700TLK
Mfg #: 3829398
Availability:In stockSpecial Price $177.61 Regular Price $213.99 -
Fluke 754HCC Smart Instrument Communication CableSmart Instrument Communication Cable
Order #: 754HCC
Mfg #: 3829410
Availability:In stockSpecial Price $121.17 Regular Price $145.99 -
Fluke TL940 Mini-Hook Test LeadsMini-Hook Test Leads
Order #: TL940
Mfg #: 1616705
Availability:In stockSpecial Price $34.85 Regular Price $41.99 -
Fluke 700TC1 T/C Mini Plug KitT/C Mini Plug Kit
Order #: 700TC1
Mfg #: 620119
Availability:In stockSpecial Price $121.17 Regular Price $145.99 -
Fluke 700TC2 T/C Mini Connector KitT/C Mini Connector Kit
Order #: 700TC2
Mfg #: 620127
Availability:In stockSpecial Price $121.17 Regular Price $145.99 -
Fluke Calibration Drywell Cable KitCable Kit, Hart Drywell Control
Order #: HART DRYWELL CABLE
Mfg #: 2111088
Availability: Ships in 1-2 weeksSpecial Price $248.15 Regular Price $263.99 -
Fluke 700IV Current ShuntCurrent Shunt
Order #: 700IV
Mfg #: 202561
Availability: Ships in 3-4 weeksSpecial Price $461.47 Regular Price $555.99 -
Fluke BP7240 HZM Li-ion Battery Pack for Fluke 753 and 754HZM Li-ion Battery Pack for Fluke 753 and 754
Order #: BP7240
Mfg #: 4022220
Availability:In stockSpecial Price $219.11 Regular Price $263.99 -
Fluke BC7240 Battery Charger/EliminatorBattery Charger/Eliminator
Order #: BC7240
Mfg #: 4022655
Availability:In stockSpecial Price $89.63 Regular Price $107.99 -
Fluke AC220 SureGrip Alligator ClipsSureGrip Alligator Clips
Order #: AC20
Mfg #: 1610103
Availability:In stockSpecial Price $53.94 Regular Price $64.99
Measurement Accuracy
| Range/Resolution | 1 Year | 2 Years | |||
|---|---|---|---|---|---|
| Voltage DC | 100.000 mV | 0.02% + 0.005 mV | 0.03% + 0.005 mV | ||
| 3.00000 V | 0.02% + 0.00005 V | 0.03% + 0.00005 V | |||
| 30.0000 V | 0.02% + 0.0005 V | 0.03% + 0.0005 V | |||
| 300.00 V | 0.05% + 0.05 V | 0.07% + 0.05 V | |||
| Voltage AC | 3.000 V (40 Hz to 500 Hz) / 0.001 V | 0.5% + 0.002 V | 1.0% + 0.004 V | ||
| 30.00 V (40 Hz to 500 Hz) / 0.01 V | 0.5% + 0.02 V | 1.0% + 0.04 V | |||
| 300.0 V (40 Hz to 500 Hz) / 0.1 V | 0.5% + 0.2 V | 1.0% + 0.2 V | |||
| Current DC | 30.000 mA | 0.01% + 5 uA | 0.015% + 7 uA | ||
| 110.00 mA | 0.01% + 20 uA | 0.015% + 30 uA | |||
| Resistance | 10.000 Ω | 0.05% + 50 mΩ | 0.07% + 70 mΩ | ||
| 100.00 Ω | 0.05% + 50 mΩ | 0.07% + 70 mΩ | |||
| 1.0000 kΩ | 0.05% + 500 mΩ | 0.07% + 0.5 Ω | |||
| 10.000 kΩ | 0.1% + 10 Ω | 0.15% + 15 Ω | |||
| Frequency | 1.00 to 110.00 Hz / 0.01 Hz | 0.05 Hz | |||
| 110.1 to 1100.0 Hz / 0.1 Hz | 0.5 Hz | ||||
| 1.101 to 11.000 kHz / 0.001 kHz | 0.005 kHz | ||||
| 11.01 to 50.00 kHz / 0.01 kHz | 0.05 kHz | ||||
Source Accuracy
| 1 Year | 2 Years | ||||
|---|---|---|---|---|---|
| Voltage DC | 100.000 mV | 0.01% + 0.005 mV | 0.015% + 0.005 mV | ||
| 1.00000 V | 0.01% + 0.00005 V | 0.015% + 0.0005 V | |||
| 15.0000 V | 0.01% + 0.0005 V | 0.015% + 0.0005 V | |||
| Current DC | 22.000 mA (source) | 0.01% + 0.003 mA | 0.02% + 0.003 mA | ||
| Current sink (simulate) | 0.02% + 0.007 mA | 0.04% + 0.007 mA | |||
| Resistance | 10.000 Ω | 0.01% + 10 mΩ | 0.015% + 15 mΩ | ||
| 100.00 Ω | 0.01% + 20 mΩ | 0.015% + 30 mΩ | |||
| 1.0000 kΩ | 0.02% + 0.2 Ω | 0.03% + 0.3 Ω | |||
| 10.000 kΩ | 0.02% + 3 Ω | 0.03% + 5 Ω | |||
| Frequency | 0.1 to 10.99 Hz | 0.01 Hz | |||
| 0.01 to 10.99 Hz | 0.01 Hz | ||||
| 11.00 to 109.99 Hz | 0.1 Hz | ||||
| 110.0 to 1099.9 Hz | 0.1 Hz | ||||
| 1.100 to 21.999 kHz | 0.002 kHz | ||||
| 22.000 to 50.000 kHz | 0.005 kHz | ||||
Technical Data
| Data log functions | Measure functions | Voltage, current, resistance, frequency, temperature, pressure | |||
| Reading rate | 1, 2, 5, 10, 20, 30, or 60 readings/minute | ||||
| Maximum record length | 8000 readings (7980 for 30 or 60 readings/minute) | ||||
| Ramp functions | Source functions | Voltage, current, resistance, frequency, temperature | |||
| Rate | 4 steps/second | ||||
| Trip detect | Continuity or voltage (continuity detection not available when sourcing current) | ||||
| Loop power function | Voltage | Selectable, 26 V | |||
| Accuracy | 10%, 18 V minimum at 22 mA | ||||
| Maximum current | 25 mA, short circuit protected | ||||
| Maximum input voltage | 50 V DC | ||||
| Step functions | Source functions | Voltage, current, resistance, frequency, temperature | |||
| Manual step | Selectable step, change with arrow buttons | ||||
| Autostep | Fully programmable for function, start delay, stepvalue, time per step, repeat | ||||
Environmental Specifications
| Operating temperature | -10°C to +50°C | ||||
| Storage temperature | -20°C to +60°C | ||||
| Dust/water resistance | Meets IP52, IEC 529 | ||||
| Operating altitude | 3000 m above mean sea level (9842 ft) | ||||
Safety Specifications
| Agency approvals | CAN/CSA C22.2 No 1010.1-92, ASNI/ISA S82.01-1994, UL3111, and EN610-1:1993 | ||||
Mechanical and General Specifications
| Size | 136 x 245 x 63 mm (5.4 x 9.6 x 2.5 in) | ||||
| Weight | 1.2 kg (2.7 lb) | ||||
| Batteries | Internal Battery Pack Li-ion: 7.2V,4400mAh, 30 Wh | ||||
| Battery life | >8 hours typical | ||||
| Battery replacement | Replace without opening calibrator; no tools required | ||||
| Side port connections | Pressure module connector | ||||
| USB Connector to interface to your PC | |||||
| Digital instrument (HART) connector | |||||
| Connection for optional battery charger/eliminator | |||||
| Data storage capacity | 1 week of calibration procedures results | ||||
| 90 day specifications | The standard specification interval for the 750 Seriesare 1 and 2 years. | ||||
| Typical 90 day measurement and source accuracy can be estimated by dividing the one year "% of reading" or "% of output" specifications by 2. | |||||
| Floor specifications, expressed as "% of full scale" or "counts" or "ohms" remain constant. | |||||
Temperature, Resistance Temperature Detectors
| Degrees or % of reading - Type (α) | Range °C | Measure °C1 | |||
| 1 year | 2 year | ||||
| 100 Ω Pt (385) | -200 to 100 | 0.07°C | 0.14°C | ||
| 100 to 800 | 0.02% + 0.05°C | 0.04% + 0.10°C | |||
| 200 Ω Pt (385) | -200 to 100 | 0.07°C | 0.14°C | ||
| 100 to 630 | 0.02% + 0.05°C | 0.04% + 0.10°C | |||
| 500 Ω Pt (385) | -200 to 100 | 0.07°C | 0.14°C | ||
| 100 to 630 | 0.02% + 0.05°C | 0.04% + 0.10°C | |||
| 1000 Ω Pt (385) | -200 to 100 | 0.07°C | 0.14°C | ||
| 100 to 630 | 0.02% + 0.05°C | 0.04% + 0.10°C | |||
| 100 Ω Pt (3916) | -200 to 100 | 0.07°C | 0.14°C | ||
| 100 to 630 | 0.02% + 0.05°C | 0.04% + 0.10°C | |||
| 100 Ω Pt (3926) | -200 to 100 | 0.08°C | 0.16°C | ||
| 100 to 630 | 0.02% + 0.06°C | 0.04% + 0.12°C | |||
| 10 Ω Cu (427) | -100 to 260 | 0.2°C | 0.4°C | ||
| 120 Ω Ni (672) | -80 to 260 | 0.1°C | 0.2°C | ||
| Source current | Source °C | Allowable current2 | |||
| 1 year | 2 year | ||||
| 1 mA | 0.05°C | 0.10°C | 0.1 mA to 10 mA | ||
| 0.0125% + 0.04°C | 0.025% + 0.08°C | ||||
| 500 μA | 0.06°C | 0.12°C | 0.1 mA to 1 mA | ||
| 0.017% + 0.05°C | 0.034% + 0.10°C | ||||
| 250 μA | 0.06°C | 0.12°C | 0.1 mA to 1 mA | ||
| 0.017% + 0.05°C | 0.034% + 0.10°C | ||||
| 150 μA | 0.06 C | 0.12 C | 0.1 mA to 1 mA | ||
| 0.017% + 0.05°C | 0.034% + 0.10°C | ||||
| 1 mA | 0.05°C | 0.10°C | 0.1 mA to 10 mA | ||
| 0.0125% + 0.04°C | 0.025% + 0.08°C | ||||
| 1 mA | 0.05°C | 0.10°C | 0.1 mA to 10 mA | ||
| 0.0125% + 0.04°C | 0.025% + 0.08°C | ||||
| 3 mA | 0.2°C | 0.4°C | 0.1 mA to 10 mA | ||
| 1 mA | 0.04°C | 0.08°C | 0.1 mA to 10 mA | ||
| 1. For two and three-wire RTD measurements, add 0.4°C to the specifications. | |||||
| 2. Supports pulsed transmitters and PLCs with pulse times as short as 1 ms | |||||
Temperature, Thermocouples
| Type | Source °C | Measure °C | Source °C | ||
| 1 year | 2 years | 1 year | 2 years | ||
| E | -250 to -200 | 1.3 | 2 | 0.6 | 0.9 |
| -200 to -100 | 0.5 | 0.8 | 0.3 | 0.4 | |
| -100 to 600 | 0.3 | 0.4 | 0.3 | 0.4 | |
| 600 to 1000 | 0.4 | 0.6 | 0.2 | 0.3 | |
| N | -200 to -100 | 1.0 | 1.5 | 0.6 | 0.9 |
| -100 to 900 | 0.5 | 0.8 | 0.5 | 0.8 | |
| 900 to 1300 | 0.6 | 0.9 | 0.3 | 0.4 | |
| J | -210 to -100 | 0.6 | 0.9 | 0.3 | 0.4 |
| -100 to 800 | 0.3 | 0.4 | 0.2 | 0.3 | |
| 800 to 1200 | 0.5 | 0.8 | 0.3 | 0.3 | |
| K | -200 to -100 | 0.7 | 1 | 0.4 | 0.6 |
| -100 to 400 | 0.3 | 0.4 | 0.3 | 0.4 | |
| 400 to 1200 | 0.5 | 0.8 | 0.3 | 0.4 | |
| 1200 to 1372 | 0.7 | 1 | 0.3 | 0.4 | |
| T | -250 to -200 | 1.7 | 2.5 | 0.9 | 1.4 |
| -200 to 0 | 0.6 | 0.9 | 0.4 | 0.6 | |
| 0 to 400 | 0.3 | 0.4 | 0.3 | 0.4 | |
| B | 600 to 800 | 1.3 | 2 | 1 | 1.5 |
| 800 to 1000 | 1 | 1.5 | 0.8 | 1.2 | |
| 1000 to 1820 | 0.9 | 1.3 | 0.8 | 1.2 | |
| R | -20 to 0 | 2.3 | 2.8 | 1.2 | 1.8 |
| 0 to 100 | 1.5 | 2.2 | 1.1 | 1.7 | |
| 100 to 1767 | 1 | 1.5 | 0.9 | 1.4 | |
| S | -20 to 0 | 2.3 | 2.8 | 1.2 | 1.8 |
| 0 to 200 | 1.5 | 2.1 | 1.1 | 1.7 | |
| 200 to 1400 | 0.9 | 1.4 | 0.9 | 1.4 | |
| 1400 to 1767 | 1.1 | 1.7 | 1 | 1.5 | |
| C | 0 to 800 | 0.6 | 0.9 | 0.6 | 0.9 |
| 800 to 1200 | 0.8 | 1.2 | 0.7 | 1 | |
| 1200 to 1800 | 1.1 | 1.6 | 0.9 | 1.4 | |
| 1800 to 2316 | 2 | 3 | 1.3 | 2 | |
| L | -200 to -100 | 0.6 | 0.9 | 0.3 | 0.4 |
| -100 to 800 | 0.3 | 0.4 | 0.2 | 0.3 | |
| 800 to 900 | 0.5 | 0.8 | 0.2 | 0.3 | |
| U | -200 to 0 | 0.6 | 0.9 | 0.4 | 0.6 |
| 0 to 600 | 0.3 | 0.4 | 0.3 | 0.4 | |
| BP | 0 to 1000 | 1 | 1.5 | 0.4 | 0.6 |
| 1000 to 2000 | 1.6 | 2.4 | 0.6 | 0.9 | |
| 2000 to 2500 | 2 | 3 | 0.8 | 1.2 | |
| XK | -200 to 300 | 0.2 | 0.3 | 0.2 | 0.5 |
| 300 to 800 | 0.4 | 0.6 | 0.3 | 0.6 | |
All products in this series
-
Fluke 754/750SW BU Fluke 754 DPC & 750SW DPCTRACK2 Software Bundle PackageFluke 754 DPC & 750SW DPCTRACK2 Bundle Package$13,208.99
-
Fluke 754 for Rent, Multifunction Documenting CalibratorMultifunction Documenting CalibratorCall for price
-
Fluke 753 VIP Kit - Documenting Process Calibrator with FREE TOOLS!Documenting Process Calibrator with FREE TOOLS!$8,520.99
-
Fluke 754 VIP KIT - Documenting Process Calibrator with FREE TOOLS!Documenting Process Calibrator w/FREE Tools!$10,413.99
-
