Order #: TCL-4502-C
Mfg #: TCL-4502
Order #: TCL-4502-C
Mfg #: TCL-4502
The TCL Series balances are available as external calibration models, allowing you to pay only for the features you need. Designed to deliver reliable weighing results in your daily work. Each Unit comes with a 5 year Warranty and Calibration certificate.
TCL-64-C | TCL-164-C | TCL-224-C | TCL-314-C | |
---|---|---|---|---|
Maximum Capacity | 62 g | 160 g | 220 g | 310 g |
Readability [d] | 0.1 mg | 0.1 mg | 0.1 mg | 0.1 mg |
Repeatability (5% Max) | 0.06 mg | 0.07 mg | 0.07 mg | 0.08 mg |
Repeatability (Max) | 0.08 mg | 0.08 mg | 0.08 mg | 0.12 mg |
Linearity | 0.2 mg | +/- 0.2 mg | +/- 0.2 mg | +/- 0.3 mg |
Adjustment | External | |||
Stabilization Time | 2 s | 2 s | 2 s | 2.5 s |
Pan Size | 100 mm (3.9 in) | |||
Unit Dimensions | 351 _ 205.5 _ 348 mm (13.8 x 8.1 x 13.7in) | |||
Communication ports | RS232, 2 x USB-A, USB-B |
TCL-363-C | TCL-603-C | TCL-1003-C | |
---|---|---|---|
Maximum Capacity | 360 g | 600 g | 1000 g |
Readability [d] | 1 mg | 1 mg | 1 mg |
Repeatability (5% Max) | 0.5 mg | 0.5 mg | 0.5 mg |
Repeatability (Max) | 1 mg | 1 mg | 1.5 mg |
Linearity | +/- 2 mg | +/- 2 mg | +/- 3 mg |
Adjustment | External | ||
Stabilization Time | 2 s | ||
Pan Size | 128 x 128 mm (5.7 x 5.7 in) | ||
Unit Dimensions | 333 _ 206 _ 100 mm (13.1 x 8.1 x 3.9in) | ||
Communication ports | 2 x RS232, USB (A and B) |
TCL-2102-C | TCL-4502-C | TCL-6002-C | |
---|---|---|---|
Maximum Capacity | 2100 g | 4500 g | 6000 g |
Readability [d] | 0.01 g | 0.01 g | 0.01 g |
Repeatability (5% Max) | 0.005 g | 0.005 g | 0.005 g |
Repeatability (Max) | 0.008 g | 0.008 g | 0.008 g |
Linearity | +/- 0.02 g | +/- 0.03 g | +/- 0.03 g |
Adjustment | External | ||
Stabilization Time | 2 s | ||
Pan Size | 195 x 195 mm (7.7 x 7.7in) | ||
Unit Dimensions | 333 _ 206 _ 100 mm (13.1 x 8.1 x 3.9in) | ||
Communication ports | 2 x RS232, USB (A and B) |
