PROCISION TCL-4502-C

Precision Balance, 4500g x 0.01g w/Calibration Certificate

Order #: TCL-4502-C

Mfg #: TCL-4502

Questions about availability or need help? Contact Us:

(800) 633-0561 sales@transcat.com

$1,987.00

Qty

PROCISION TCL-4502-C

Precision Balance, 4500g x 0.01g w/Calibration Certificate

Order #: TCL-4502-C

Mfg #: TCL-4502

FREE Calibration Weight

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$1,987.00

The TCL Series balances are available as external calibration models, allowing you to pay only for the features you need. Designed to deliver reliable weighing results in your daily work. Each Unit comes with a 5 year Warranty and Calibration certificate.

Availability: Ships in 3-4 weeks

Ships Free Over $100

Product Overview

Product Highlights

Max Capacity: 4500g
Readability: 0.01 g
Repeatability (5% Max): 0.005 g
Repeatability (Max): 0.008 g
Linearity: +/-0.03 g
Stabilization Time: 2 s
Unit Dimensions: 333 x 206 x 100 mm (13.1 x 8.1 x 3.9in)
Weighing Pan Dimensions: 195 x 195mm
5-year warranty_
Calibration certificate included
Externally calibrating- requires purchase of a F2 2000g calibration weight_
USB (A&B) and RS-232 Communication Interfaces_
Large, backlit LCD display

Specifications

Analytical Balances

	TCL-64-C	TCL-164-C	TCL-224-C	TCL-314-C
Maximum Capacity	62 g	160 g	220 g	310 g
Readability [d]	0.1 mg	0.1 mg	0.1 mg	0.1 mg
Repeatability (5% Max)	0.06 mg	0.07 mg	0.07 mg	0.08 mg
Repeatability (Max)	0.08 mg	0.08 mg	0.08 mg	0.12 mg
Linearity	0.2 mg	+/- 0.2 mg	+/- 0.2 mg	+/- 0.3 mg
Adjustment	External
Stabilization Time	2 s	2 s	2 s	2.5 s
Pan Size	100 mm (3.9 in)
Unit Dimensions	351 _ 205.5 _ 348 mm (13.8 x 8.1 x 13.7in)
Communication ports	RS232, 2 x USB-A, USB-B

Milligram Balances

	TCL-363-C	TCL-603-C	TCL-1003-C
Maximum Capacity	360 g	600 g	1000 g
Readability [d]	1 mg	1 mg	1 mg
Repeatability (5% Max)	0.5 mg	0.5 mg	0.5 mg
Repeatability (Max)	1 mg	1 mg	1.5 mg
Linearity	+/- 2 mg	+/- 2 mg	+/- 3 mg
Adjustment	External
Stabilization Time	2 s
Pan Size	128 x 128 mm (5.7 x 5.7 in)
Unit Dimensions	333 _ 206 _ 100 mm (13.1 x 8.1 x 3.9in)
Communication ports	2 x RS232, USB (A and B)

Toploading Balances

	TCL-2102-C	TCL-4502-C	TCL-6002-C
Maximum Capacity	2100 g	4500 g	6000 g
Readability [d]	0.01 g	0.01 g	0.01 g
Repeatability (5% Max)	0.005 g	0.005 g	0.005 g
Repeatability (Max)	0.008 g	0.008 g	0.008 g
Linearity	+/- 0.02 g	+/- 0.03 g	+/- 0.03 g
Adjustment	External
Stabilization Time	2 s
Pan Size	195 x 195 mm (7.7 x 7.7in)
Unit Dimensions	333 _ 206 _ 100 mm (13.1 x 8.1 x 3.9in)
Communication ports	2 x RS232, USB (A and B)
